Burley Thru Axle 12 X 1.75 (174-180mm)

SPECS:

Thread Pitch :	Measured Axle Length:	Compatible Burley Thru Axle:	Includes:
1.0	160-174mm	12 x 1.0, 142-148mm	One conical spacer and One flat spacer
1.5	172-178mm actual length	12 x 1.5, for 142-148mm	One flat spacer
1.75	174-180mm	12 x 1.75, for 142-148mm	One flat spacer
1.75	192-198mm	12 x 1.75, for 142-148mm, Long	One flat spacer

DESIGN:

• Specially designed for use with the Coho XC
• Thru axle is slightly longer so that it can stick out on the right side of the frame to attach the hitch mount

FEATURES:

• Official Burley adapter for bikes with 12mm rear thru axles
• Quick and easy installation
• Accessories included: Thru axle and hitch mounts

ADDITIONAL DETAILS:

• If you are unsure of the correct thread pitch or hub length, please consult with the manufacturer of your bike, or your local bike shop before purchasing a Burley Thru Axle
• Burley Thru Axle is not compatible with all carbon fiber bike frames (consult manual)
